Heavy Duty Ratchet Type Load Binder, Ratchet Loadbinders for Lashing

  • DAWSON/OEM
  • DS-RLB
  • 16000lbs
  • 1000pcs
Availability:
Quantity:

Heavy Duty Ratchet Type Load Binder, Ratchet Loadbinders for Lashing
- Dawson Group Ltd. - China Manufacturer, Supplier, Factory




Heavy Duty Ratchet Type Load Binder, Ratchet Loadbinders for Lashing - Dawson Group Ltd. - China Manufacturer, Supplier, Factory


Heavy Duty Ratchet Type Load Binder with Hook and Hook ( Two Piece Handles)

Heavy Duty Ratchet Type Load Binder with Two Piece Handles - Dawson Group Ltd. - China Manufacturer, Supplier, Factory


Meets or exceeds DOT and CVSA Cargo Securement Tie-Down Guideline

Forged-Quenched and Tempered with 100% Proof Tested

Powder Coated or Yellow Zinc Plated

Material Certificates and Testing Reports available when requested at the time of order

Heavy duty swaged tube body

Two piece handle

Ultimate load is 3 times the WLL.

Packing available with Carton Box

PART NUMBER CHAIN SIZE TAKE-UP BARREL LENGTH HANDLE LENGTH SCREW DIA. WLL(LBS.) PROOF LOAD LIMIT(LBS.) WEIGHT/PC
(LBS.)
DS-RLB025 5/16-3/8 8’’ 10’’ 15.5’’ 1’’ 8800 17600 13
DS-RLB026 3/8-1/2 8’’ 10’’ 15.5’’ 1’’ 12000 24000 14
DS-RLB027 1/2-5/8 8’’ 10’’ 15.5’’ 1’’ 18100 362000 16


Heavy Duty Ratchet Type Load Binder with Two Piece Handles for Lashing

Heavy Duty Ratchet Type Load Binder with Two Piece Handles for Lashing - Dawson Group Ltd. - China Manufacturer, Supplier, Factory


Meets or exceeds DOT and CVSA Cargo Securement Tie-Down Guideline

Forged-Quenched and Tempered with 100% Proof Tested

Powder Coated or Yellow Zinc Plated

Material Certificates and Testing Reports available when requested at the time of order

Heavy duty swaged tube body

Two piece handle

Ultimate load is 3 times the WLL.

Packing available with Carton Box

PART NUMBER CHAIN SIZE TAKE-UP BARREL LENGTH HANDLE LENGTH SCREW DIA. WLL(LBS.) PROOF LOAD LIMIT(LBS.) WEIGHT/PC(LBS.)
DS-RLB028 1/2-5/8 8’’ 10’’ 15.5’’ 1’’ 16000 32000 14

Heavy Duty Ratchet Type Load Binder with Hooks for Lashing ( One Piece Handle )

Heavy Duty Ratchet Type Load Binder with One Piece Handle for Lashing - Dawson Group Ltd. - China Manufacturer, Supplier, Factory


Meets or exceeds DOT and CVSA Cargo Securement Tie-Down Guideline

Forged-Quenched and Tempered with 100% Proof Tested

Powder Coated or Yellow Zinc Plated

Material Certificates and Testing Reports available when requested at the time of order

Heavy duty swaged & tapered tube body

One piece handle

Ultimate load is 3 times the WLL.

Packing available with Carton Box

PART NUMBER CHAIN SIZE TAKE-UP BARREL LENGTH HANDLE LENGTH SCREW DIA. WLL(LBS.) PROOF LOAD LIMIT(LBS.) WEIGHT/PC(LBS.)
DS-RLB029 5/16-3/8 8’’ 10’’ 15.5’’ 1’’ 7100 14200 9
DS-RLB030 5/16-3/8 8’’ 10’’ 15.5’’ 1’’ 8800 17600 11
DS-RLB031 3/8-1/2 8’’ 10’’ 15.5’’ 1’’ 12000 24000 14
DS-RLB032 3/8-1/2 8’’ 10’’ 15.5’’ 1’’ 15000 30000 16
DS-RLB033 1/2-5/8 8’’ 10’’ 15.5’’ 1’’ 13000 26000 16
DS-RLB034 1/2-5/8 8’’ 10’’ 15.5’’ 1’’ 16000 32000 18
DS-RLB035 1/2-5/8 8’’ 10’’ 15.5’’ 1’’ 18100 36200 18


Heavy Duty Ratchet Type Load Binder without Links & Hooks for Lashing ( One Piece Handle )

Heavy Duty Ratchet Type Load Binder with One Piece Handle for Lashing - Dawson Group Ltd. - China Manufacturer, Supplier, Factory


Meets or exceeds DOT and CVSA Cargo Securement Tie-Down Guideline

Forged-Quenched and Tempered with 100% Proof Tested

Powder Coated or Yellow Zinc Plated

Material Certificates and Testing Reports available when requested at the time of order

Heavy duty swaged & tapered tube body

One piece handle

Ultimate load is 3 times the WLL.

Packing available with Carton Box

PART NUMBER CHAIN SIZE TAKE-UP BARREL LENGTH HANDLE LENGTH SCREW DIA. WLL(LBS.) PROOF LOAD LIMIT(LBS.) WEIGHT/PC(LBS.)
DS-RLB029 5/16-3/8 8’’ 10’’ 15.5’’ 1’’ 7100 14200 9
DS-RLB030 5/16-3/8 8’’ 10’’ 15.5’’ 1’’ 8800 17600 11
DS-RLB031 3/8-1/2 8’’ 10’’ 15.5’’ 1’’ 12000 24000 14
DS-RLB032 3/8-1/2 8’’ 10’’ 15.5’’ 1’’ 15000 30000 16
DS-RLB033 1/2-5/8 8’’ 10’’ 15.5’’ 1’’ 13000 26000 16
DS-RLB034 1/2-5/8 8’’ 10’’ 15.5’’ 1’’ 16000 32000 18
DS-RLB035 1/2-5/8 8’’ 10’’ 15.5’’ 1’’ 18100 36200 18


Heavy Duty Ratchet Type Load Binder with Slip Hook & Grab Hook

Heavy Duty Ratchet Type Load Binder with Slip Hook & Grab Hook - Dawson Group Ltd. - China Manufacturer, Supplier, Factory


Meets or exceeds DOT and CVSA Cargo Securement Tie-Down Guideline

Forged-Quenched and Tempered with 100% Proof Tested

Powder Coated or Yellow Zinc Plated

Material Certificates and Testing Reports available when requested at the time of order

Heavy duty swaged & tapered tube body

One piece handle

Ultimate load is 3 times the WLL.

Packing available with Carton Box

PART NUMBER CHAIN SIZE TAKE-UP BARREL LENGTH HANDLE LENGTH SCREW DIA. WLL(LBS.) PROOF LOAD LIMIT(LBS.) WEIGHT/PC(LBS.)
DS-RLB036 3/8-1/2 8’’ 10’’ 15.5’’ 1’’ 12000 24000 17


Heavy Duty Ratchet Type Load Binder with Slip Hook & Two Grab Hooks

Heavy Duty Ratchet Type Load Binder with Slip Hook & Two Grab Hooks - Dawson Group Ltd. - China Manufacturer, Supplier, Factory


Meets or exceeds DOT and CVSA Cargo Securement Tie-Down Guideline

Forged-Quenched and Tempered with 100% Proof Tested

Powder Coated or Yellow Zinc Plated

Material Certificates and Testing Reports available when requested at the time of order

Heavy duty swaged & tapered tube body

One piece handle

Ultimate load is 3 times the WLL.

Packing available with Carton Box

PART NUMBER CHAIN SIZE TAKE-UP BARREL LENGTH HANDLE LENGTH SCREW DIA. WLL(LBS.) PROOF LOAD LIMIT(LBS.) WEIGHT/PC(LBS.)
DS-RLB037 5/16-3/8 8’’ 10’’ 15.5’’ 1’’ 8800 17600 16
DS-RLB038 3/8-1/2 8’’ 10’’ 15.5’’ 1’’ 15000 30000 18
DS-RLB039 1/2-5/8 8’’ 10’’ 15.5’’ 1’’ 16000 32000 20


T Handle Ratchet Type Load Binder

T Handle Ratchet Type Load Binder - Dawson Group Ltd. - China Manufacturer, Supplier, Factory


Meets or exceeds DOT and CVSA Cargo Securement Tie-Down Guideline

Forged-Quenched and Tempered with 100% Proof Tested

Powder Coated or Yellow Zinc Plated

Material Certificates and Testing Reports available when requested at the time of order

One piece T handle for easy grip

Packing available with Carton Box

Great for the towing industry

PART NUMBER CHAIN SIZE TAKE-UP BARREL LENGTH HANDLE LENGTH SCREW DIA. WLL(LBS.) PROOF LOAD LIMIT(LBS.) WEIGHT/PC(LBS.)
DS-RLB040 5/16-3/8 8’’ 10’’ 15.5’’ 7/8’’ 7100 14200 10


Australia Type Ratchet Type Load Binder with Wing Hook

Australia Type Ratchet Type Load Binder with Wing Hook - Dawson Group Ltd. - China Manufacturer, Supplier, Factory    Australia Type Ratchet Type Load Binder with Wing Hook - Dawson Group Ltd. - China Manufacturer, Supplier


Meets performance requirements of AS/NZ4344:2001 standard

Forged-Quenched and Tempered with 100% Proof Tested

Finish:Powder Coated

Material Certificates and Testing Reports available when requested at the time of order

Packing available with Carton Box

Option Barrel with/without safety device

PART NUMBER SIZE WLL(Kg) MBL(Kg) WEIGHT(Kg) DIMENSION(mm)
A C E1 E G
DS-RLB041 6mm 2300 4600 1.9 206 42 415 515 9.7
DS-RLB042 7-8mm 3800 8600 4.9 355 65 590 754 11
DS-RLB043 10mm 6000 12000 5.4 355 65 610 775 12
DS-RLB044 13mm 9000 18000 7.5 355 65 700 870 15


Specialty Baler Binders, Heavy Duty Long Collared Jaw & Jaw Load Binder

Specialty Baler Binders, Heavy Duty Load Binder Jaw & Jaw - Dawson Group Ltd. - China Manufacturer, Supplier, Factory


PAPT NUMBER BERREL LENGTH(IN.) WHEEL DIAM.(IN.) WLL(LBS.) MBS(LBS.)
DS-RLB049 12’’ 10’’ 28000 85000
DS-RLB050 24’’ 10’’ 28000 85000


Welcome to buy the newest and competitive price DAWSON Heavy Duty Ratchet Type Load Binder, Ratchet Loadbinders for Lashing from our factory. We're one of the leading China manufacturers and suppliers, offering you the wholesale service and the OEM service at a discount. With CE certification, our products made in China in stock are high in quality and low in price. Please be free to get the free sample from us.


Ratchet Type Load Binders
Ratchet Load Binder Fits Chain Size 3/8'' - 5/16'' WLL 8800Lbs Folding Handle Ratchet Binder with Eye Grab Hook for Chain Size 5/16''- 3/8'' WLL 7100LBS
WLL 8800Lbs 3/8'' - 5/16'' Ratchet Type Load Binder with Eye Grab Hook G100 Ratchet Binder With Safety Hooks, Grade 100 Load Binder for Lashing
G100 Clevis Type Ratchet Binder, Grade 100 Forged Load Binder G100 Ratchet Binder Without Links And Hooks, Grade 100 Load Binder for Lashing
G80 Lashing Chains with Ratchet, Grade 80 Ratchet Chain Lashing G80 Ratchet Binder With Safety Hooks to EN 12195-3, Grade 80 Ratchet Type Load Binder
Alloy Steel Drop Forged Ratchet Type Load Binder Without Links Or Hooks High Quality Drop Forged Ratchet Type Load Binder, Loadbinders
Lever Type Load Binder With Grab Hook, Forged Steel Lever Chain Binder Spring Load Binder, Spring Loaded Lever Type Load Binders
Drop Forged Indirect Load Binder, Heat Treated Load Binders Lever Type Load Binder With Claw Hook, Forged Claw Load Binder

Other Products:



Supply only on special request.Not for recommendation.

For further information, please contact us. Email:info@dawson-group.com


Ratchet Binder LB001 - Dawson Group LTD. - China Manufacturer, Supplier, Factory

Ratchet Binder LB001
Ratchet Binder LB002 - Dawson Group LTD. - China Manufacturer, Supplier, Factory

Ratchet Binder LB002
Ratchet Binder LB003 - Dawson Group LTD. - China Manufacturer, Supplier, Factory

Ratchet Binder LB003


Hot Tags: ratchet type load binder,ratchet load binder,heavy duty ratchet load binder,heavy duty load binder,drop forged load binders,load bidners with two piece handles,ratchet load bidners with one piece handle,ratchet load binder for lashing,heavy duty swaged tube body,heavy duty loadbinder for lashing


Other related products:

Specialty Baler Binders, Heavy Duty Load Binder Jaw & Jaw - Dawson Group Ltd. - China Manufacturer, Supplier
Ratchet Load Binder, Loadbinder for Lashing - Dawson Group Ltd. - China Manufacturer, Supplier, Factory
Heavy Duty Ratchet Type Load Binder with Slip Hook & Grab Hook - Dawson Group Ltd. - China Manufacturer, Supplier
Heavy Duty Ratchet Type Load Binder with Two Piece Handles for Lashing - Dawson Group Ltd. - China Manufacturer, Supplier
Heavy Duty Ratchet Type Load Binder with Slip Hook & Two Grab Hooks - Dawson Group Ltd. - China Manufacturer, Supplier

Heavy Duty Ratchet Type Load Binder with Two Piece Handles - Dawson Group Ltd. - China Manufacturer, Supplier
Heavy Duty Ratchet Type Load Binder with Grab Hook & Jaw - Dawson Group Ltd. - China Manufacturer, Supplier
Heavy Duty Ratchet Type Load Binder with One Piece Handle, Eye and Eye LoadBinder - Dawson Group Ltd. - China Manufacturer, Supplier

Load Binder - Dawson Group Ltd. - China Manufacturer, Supplier, Factory
Load Binder - Dawson Group Ltd. - China Factory, Manufacturer, Supplier
Ratchet Binder - Dawson Group Ltd. - China Factory, Manufacturer, Supplier
Load Binders - Dawson Group Ltd. - China Factory, Manufacturer, Supplier

Application of Load Binder:

Application of Load Binders - Dawson Group Ltd. - China Factory, Supplier, Manufacturer

Application of Ratchet Type Load Binder - Dawson Group LTD. - China Manufacturer, Supplier, Factory



Factory & Package Show:

Package of Ratchet Binder - Dawson Group Ltd. - China Factory, Manufacturer, Supplier

Factory of Heavy Duty Ratchet Type Load Binder, Ratchet Loadbinders for Lashing - Dawson Group Ltd. - China Manufacturer, Supplier, Factory
