WLL 60 Ton Heavy Duty Polyester Webbing Slings - Lifting Slings Crane Slings

-Color coded according to EN 1492-1.
-According to Machine Directive 98/37/EC.
-Safety Factor: 7:1
-Safety Factor of 6:1 or 5:1 is available upon request
  • DAWSON/OEM

  • 60T

Availability:
Quantity:

WLL 60 Ton Heavy Duty Polyester Webbing Slings - Lifting Sling, Crane Lifting Slings
- Dawson Group Ltd. - China Manufacturer, Supplier, Factory

DAWSON WLL 60 Ton Heavy Duty Polyester Webbing Slings - Lifting Slings Crane Slings - Dawson Group Ltd. - China Manufacturer, Supplier, Factory   DAWSON WLL 60 Ton Heavy Duty Polyester Webbing Slings - Lifting Slings Crane Slings - Dawson Group Ltd. - China Manufacturer, Supplier

1.Product Summary



Dawson Flat Webbing Sling is woven with machine for one time, and processed in the different sewing methods, it can be used the strengthened eye on its ends to improve its strength. Its standard tonnage can be distinguished through the color, and the wide and smooth loading surface especially applies to the articles with the soft surface and if necessary, the protective sleeve which is wider than sling can be used. Because of no contacting metal, it causes hardly damage to the loaded article surface processed with lacquer. Flat woven webbing sling made from polyester can not cause sparkle if it is used under the hazardous and explosive environment. In addition, its low extending property can decrease the bound of load in the courses of lifting, and avoid damage from the shocking strength. At the same time, make codes for the dyeing colors of sling and suggest the simple and correct methods for loading, which is well convenient for our lifting user.



2. Technical Data

Material: polyester polypropylene

Safe Factor: 5:1 6:1 7:1 8:1

Standard : ISO4878  EN1492-1:2000 JB/T8521-2000

Length: as required

Color: color code

Ply: single. Double. three and four-ply


3. Type

A. Eye and Eye Flat Webbing Sling

a, Single-ply Eye and Eye Flat Webbing Sling

b, Double-ply Eye and Eye Flat Webbing Sling

c, Three-ply Eye and Eye Flat Webbing Sling

d, Four-ply Eye and Eye Flat Webbing Sling

  Remark: Sling eye is divided into flat eye, reverse eye, eye folded 1/2 from one side, eye folded 1/2 from two sides and eye folded 1/3.



B, Endless Flat Webbing Sling

a, Single-ply Endless Flat Webbing Sling

b, Double-ply Endless Flat Webbing Sling

c, Three-ply Endless Flat Webbing Sling

d, Four-ply Endless Flat Webbing Sling

Polyester Flat Webbing Slings - Dawson Group Ltd. - China Manufacturer, Supplier, Factory

Type

-Double ply polyester webbing sling with reinforced lifting eyes

Technical specifications

-Colour coded according to EN 1492-1.

Characteristics

-Low elongation.

Norms

-According to Machine Directive 98/37/EC.

-Safety Factor: 7:1

-Safety Factor of 6:1 or 5:1 is available upon request

Polyester Lifting Slings Flat Webbing Sling - Dawson Group Ltd. - China Manufacturer, Supplier, Factory
Polyester Websling - Dawson Group Ltd. - China Supplier, Factory Item Color coded
according to
EN
1492-1
Working Load Limit with 1 webbing sling Working Load Limit with 2 webbing sling
Straight
lift
Choked
lift
β
Straight
lift up to
45
Choked
lift up to
45
Straight
lift
45-60
Choked
lift
45-60
0-7 7-45 45-60
straight choked 0-7 7-45 45-60 straight to 45 choked to 45 straight 45-60 choked 45-60
1.0 0.8 2.0 1.4 1.0 1.4 1.12 1.0 0.8
DSWSDP-201 WLL 1T 1.000 800 2.000 1.400 1.000 1.400 1.120 1.000 800
DSWSDP-202 WLL 2T 2.000 1.600 4.000 2.800 2.000 2.800 2.240 2.000 1.600
DSWSDP-203 WLL 3T 3.000 2.400 6.000 4.200 3.000 4.200 3.360 3.000 2.400
DSWSDP-204 WLL 4T 4.000 3.200 8.000 5.600 4.000 5.600 4.480 4.000 3.200
DSWSDP-205 WLL 5T 5.000 4.000 10.000 7.000 5.000 7.000 5.600 5.000 4.000
DSWSDP-206 WLL 6T 6,000 4,800 12,000 8,400 6,000 8,400 6,720 6,000 4,800
DSWSDP-208 WLL8T 8,000 6,400 16,000 11,200 8,000 12,000 8,960 8,000 6,400
DSWSDP-210 WLL10T 10,000 8,000 20,000 14,000 10,000 14,000 11,200 10,000 8,000
DSWSDP-212 WLL 12T 12,000 9,600 24,000 16,800 12,000 16,800 13,440 12,000 9,600

Welcome to buy the newest and competitive price DAWSON  WLL 60 Ton Heavy Duty Polyester Webbing Slings - Lifting Slings Crane Slings from our factory. We're one of the leading China manufacturers and suppliers, offering you the wholesale service and the OEM service at a discount. With CE certification, our products made in China in stock are high in quality and low in price. Please be free to get the free sample from us.
