SPM (Double Braided Nylon Rope)

SPM ropes is in adopting a double circular structure, this is a kind of innovation design, compared with the traditional structure of the ropes, has higher strength and better abrasion resistance and longer service life.

Both eyes in the end are come with a metal thimble, polyester jacket should be covering the rope where it has the thimble (the thickness of jacket is not less than 6mm), then the rope outer coating a layer of polyurethane glue, to increase the wear resistance of the rope. The rope from the set of 25 feet began to add floating ring, the number of floating shall meet the prescribed requirements.

Cable manufacturing OCIMF standard requirements.

Main performance

Material: Polyamide (nylon 66)

Construction: Load-bearing cores with a protective cover of polyamide

Application: Marine fishing

Colour of Rope: White with green marker

Approx. Spec. Density 1.14 not floating

Melting Point: 215℃

Abrasion Resistance: Excellent

U.V. Resistance: Excellent

Temperature Resistance: 80℃ max continuous

Dry & wet conditions: Wet strength ±5% lower than dry strength

SPM Polyamide Hawsers are manufactured in accordance with OCIMF 2000 regulations

Weight: ±5% Tolerance

DIA		CIR	WT	Single Leg Type MBL		Grommet Type MBL
MM	INCH	INCH	KGS/100M	TON	KN	TON	KN
80	3-5/32	10	406	132	1290	237	2320
88	3-7/16	11	506	167	1630	300	2940
96	3-13/16	12	585	191	1870	344	3370
104	4-1/8	13	699	222	2180	410	4020
112	4-7/16	14	798	263	2580	473	4640
120	4-3/4	15	914	298	2920	537	5260
128	5-1/16	16	1031	335	3280	603	5910
136	5-3/8	17	1164	382	3750	688	6740
144	5-11/16	18	1316	429	4210	773	7580
152	6	19	1490	478	4680	860	8430
160	6-5/16	20	1624	526	5160	947	9280
168	6-5/8	21	1785	574	5620	1033	10120
176	6-15/16	22	1986	641	6280	1153	11300
184	7-1/4	23	2165	693	6790	1248	12230
192	7-9/16	24	2351	741	7260	1334	13070
200	7-7/8	25	2554	811	7940	1459	14300
208	8-3/16	26	2756	884	8670	1592	15600
216	8-1/2	27	2957	952	9330	1714	16800
224	8-13/16	28	3161	1026	10050	1846	18090
232	9-1/8	29	3390	1094	10720	1969	19300
240	9-7/16	30	3628	1173	11500	2112	20700
248	9-3/4	31	3874	1257	12320	2262	22170
256	10-1/16	32	4128	1340	13130	2411	23630
Other sizes can be customized

SPM Single Hawser (With Protected Soft Eye)

SPM Hawser Grommet (With Protected Soft Eye)

SPM Single Hawser (With Cast P.U. Encapsulated Thimble)

SPM Hawser Grommet (With Cast P.U. Encapsulated Thimble)

SPM Single Hawser (With P.U. Encapsulated Tubular Thimble)

SPM Hawser Grommet (With P.U. Encapsulated Tubular Thimble)

Hot Tags: SPM ropes,double braided nylon rope,SPM single hawser,SPM hawser grommet,polyamide nylon rope,SPM,SPM ropes for marine fishing,SPM polyamide hawsers,polyamide hawsers,fiber rope

Application of SPM (Double Braided Nylon Rope):
