Forged super alloy steel - Quenched and Tempered.
Individually proof test at 2.5 times Working Load Limit.
Fatiuge tested at 1.5 times Working Load Limit for 20000 cycles.
Breakage test.
100% magnaflux crack detection.
Surface finish: Powder plastified.
Colour code:Red RAL3020/Yellow RAL1003
| Item No. | Weight/kg | WLL/T | B.L/T | A±1 | B±1 | N | M | D | L±2 |
| DS292-M12 | 0.23 | 1.25 | 5 | 24.8 | 35 | 23.6 | 12 | 34 | 112 |
| DS292-M14 | 0.24 | 1.5 | 6 | 24.8 | 35 | 23.6 | 14 | 34 | 112 |
| DS292-M16 | 0.31 | 1.87 | 7.48 | 24.8 | 35 | 23.6 | 16 | 34 | 112 |
| DS292-M18 | 0.5 | 2.5 | 10 | 30.4 | 44 | 31.5 | 18 | 40 | 130 |
| DS292-M20 | 0.5 | 3.12 | 12.48 | 30.4 | 43 | 31.5 | 20 | 40 | 129 |
| DS292-M24 | 2.11 | 3.15 | 12.6 | 48 | 130 | 49.5 | 24 | 67 | 268 |
| DS292-M27 | 2.00 | 6.25 | 25 | 48 | 73 | 49.5 | 27 | 67 | 211 |
| DS292-M30 | 2.11 | 7.5 | 30 | 48 | 73 | 49.5 | 30 | 67 | 211
|
Ultimate load is 4 times the Working Load Limit.
Product specifications:
M12 G80 Lifting Eye Screw, M14 G80 Lifting Eye Screw, M16 G80 Lifting Eye Screw, M18 G80 Lifting Eye Screw, M20 G80 Lifting Eye Screw, M24 G80 Lifting Eye Screw, M27 G80 Lifting Eye Screw, M30 G80 Lifting Eye Screw
M12 Grade 80 Lifting Anchor Eye Bolt, M14 Grade 80 Lifting Anchor Eye Bolt, M16 Grade 80 Lifting Anchor Eye Bolt, M18 Grade 80 Lifting Anchor Eye Bolt, M20 Grade 80 Lifting Anchor Eye Bolt, M24 Grade 80 Lifting Anchor Eye Bolt, M27 Grade 80 Lifting Anchor Eye Bolt, M30 Grade 80 Lifting Anchor Eye Bolt
Welcome to buy the newest and cheap DAWSON Grade 80 / G80 Lifting Eye Screw with Omega Link from our factory. We're one of the leading China manufacturers and suppliers, offering you the wholesale service and the OEM service at a discount. With CE certification, our products made in China in stock are high in quality and low in price. Please be free to get the free sample from us.
