Forged or welded super alloy steel.
Suitable for use with G100 chain.
It can adjust the length of chains.
It has a safety pin so that it is safer
It is forged by special alloy steel with high intensity and high toughness, and then it is heat treated.
25% stronger than G80.
Individually proof tested at 2.5 times Working Load Limit.
100% Magnaflux Crack Detection.
Fatigue tested at 1.5 times Working Load Limit for 20000 cycles.
Meet standard EN1677.
Strict break load test.
Surface finish: Powder plastified
Colour: blue RALcode: RAL5015
All load pin are 100% individually inspected and tested.
| Item No. | Weight/kg | WLL/T | B.L/T | A±1 | B±0.8 | d±0.5 | D±0.5 | E±0.5 | L±2 |
| 10-DS1023-8 | 0.5 | 2.5 | 10 | 35 | 25 | 12 | 16.5 | 10.5 | 110 |
| 10-DS1023-10 | 1.0 | 4 | 16 | 44 | 32 | 15 | 21 | 13 | 136.5 |
| 10-DS1023-13 | 2.2 | 6.7 | 26.8 | 57 | 40 | 20.5 | 27.5 | 15.5 | 180
|
Product specifications:
8MM G100 Eye Grab Hook, 10MM G100 Eye Grab Hook, 13MM G100 Eye Grab Hook
8MM Grade 100 Eye Hook, 10MM Grade 100 Eye Hook, 13MM Grade 100 Eye Hook
Adjust G100 chain length.
With safety pin.
G100 Rigging Hardware
All the Grade 100 rigging hardware is forged or welded by special alloy steel. It can be matched with G100 chains. It can be used in situations such as oil field hoisting, mine hoisting, port hoisting, forest logging hoisting etc.
Welcome to buy the newest and competitive price DAWSON G100 / Grade 100 Special Eye Grab Hook with Safety Pin for Adjust Chain Length from our factory. We're one of the leading China manufacturers and suppliers, offering you the wholesale service and the OEM service at a discount. With CE certification, our products made in China in stock are high in quality and low in price. Please be free to get the free sample from us.
Products Show:
Other related products:
Hot Tags: Eye Grab Hook, Eye Grab Hook with Safety Pin, Hot Sale Eye Grab Hook for Chain Slings, Wholesale Eye Grab Hook, G100 Eye Grab Hook China Supplier, Grade 100 Eye Grab Hook China Factory, Low Pirce Eye Grab Hook, Buy Discount Eye Grab Hook for Chian Slings, Eye Grab Hook In Stock, Eye Grab Hook OEM, Eye Grab Hook CE Certification, Special Eye Grab Hook, Special Hook for Adjust Chain Length, Locking Pin Grab Hook, Eye Grab Hook Manufacturer China
