DS1012 G100 Master Link Assembly With Flat for Wire Rope Lifting Slings

Features
● It is forged by special alloy steel with high intensity and high toughness, and then it is heat treated.
● It can be matched with G100 chains.
● The performance is increased by 25% compared with G80 products.
● Each work piece should pass testing at 2.5 times of working load limit.
● We should carry out sampling and 20000 times of fatigue testing.
● We should carry out strict sampling and breakage testing for each batch of products.
● We should carry out 100% magnetic powder flaw detection.
● Surface treatment: plastics spraying.
● Color code: Blue RAL5015.
● All sizes are forged.

  • DAWSON/OEM
  • DS1012
  • 1.3-26kg
  • 1000pcs
Quantity:

G100 / Grade 100 Master Link Assembly With Flat for Wire Rope Lifting Slings

 DS1012 G100 Master Link Assembly
- Dawson Group Ltd. - China Manufacturer, Supplier, Factory

DS1012 G100 Master Link Assembly - DAWSON GROUP LTD. - CHINA MANUFACTURER, SUPPLIER, FACTORY      DS1012 G100 Master Link Assembly - DAWSON GROUP LTD. - CHINA MANUFACTURER, SUPPLIER, FACTORY
G100 Master Link Assembly, Grade 100 Sub Master Link for Lifting Chains - China Manufacturer, Supplier - Dawson Group Ltd.      G100 Welded Main Master Link, Grade 100 Sub Link Master Link for Chains - China Supplier, Factory - Dawson Group Ltd.
G100 Alloy Steel Master Link, Master Link Assembly for G100 Chains - China Manufacturer, Supplier - Dawson Group Ltd.    G100 Master Link Assembly, Grade 100 Alloy Steel MainMaster Link for Chain Slings - China Factory, Exporter - Dawson Group Ltd.

G100 Rigging Hardware

All the Grade 100 rigging hardware is forged or welded by special alloy steel. It can be matched with G100 chains. It can be used in situations such as oil field hoisting, mine hoisting, port hoisting, forest logging hoisting etc.


Features

● It is forged by special alloy steel with high intensity and high toughness, and then it is heat treated.

● It can be matched with G100 chain.

● The performance is increased by 25% compared with G80 products.

● Each work piece should pass testing at 2.5 times of working load limit.

● We should carry out sampling and 20000 times of fatigue testing.

● We should carry out strict sampling and breakage testing for each batch of products.

● We should carry out 100% magnetic powder flaw detection.

● Surface treatment: plastics spraying.

● Color code: Blue RAL5015.

● All sizes are forged.

Item No. G100 Chain for 3/4 Legs Sling Weight/kg WLL/T A B D a b d
10-DS1012-6 6MM 1.3 3 135 75 19 54 25 13
10-DS1012-8 8MM 2.33 5.3 160 90 23 70 34 16.5
10-DS1012-10 10MM 3.7 8 180 100 27 85 40 19
10-DS1012-13 13MM 6.5 14 200 110 33 115 50 23
10-DS1012-16 16MM 10.1 21.2 260 140 36 140 65 27
10-DS1012-20 19/20MM 22.8 33.6 350 190 50 180 70 33
10-DS1012-22 22MM 26 33.9 350 190 50 180 100 36

Ultimate load is 5 times the working load limit.

All sizes: Main Link: forged Sub Link:welded

According to EN1677-4.

All sizes:there will be pressing flat only on request.

The pressing flat is for use with DS1027-G100 OMEGA LINK.


Welcome to buy the newest and competitive price DAWSON g100 Master Link Assembly forged super alloy steel from our factory. We're one of the leading China manufacturers and suppliers, offering you the wholesale service and the OEM service at a discount. With CE certification, our products made in China in stock are high in quality and low in price. Please be free to get the free sample from us.


Other Related G100  COMPONENTS

Supply only on special request. Not for recommendation.
