DS-HSH-A 623 Series Lever Block for Telecommunication for Installing Equipment

  • DAWSON/OEM

  • DS-HSH-A 623

Availability:
Quantity:

DS-HSH-A 623 Series Lever Block for Bulk Strapping
Lever Hoist for Pulling Mechanical Parts, Manual Lever Hoist for Lashing
- Dawson Group Ltd. - China Manufacturer, Supplier, Factory

DS-HSH-A 623 Series Lever Block - Dawson Group LTD. - China Manufacturer, Supplier, Factory       Drawing of DS-HSH-A 623 Series Lever Block - Dawson Group LTD. - China Manufacturer, Supplier, Factory
Model   HSH-0.75A HSH-1.5A HSH-3A HSH-6A HSH-9A
Capacity tons 0.75 1.5 3 6 9
Standard lift m 1.5 1.5 1.5 1.5 1.5
Running test load Kn 11.0 22.0 37.5 75.0 112.5
Effort required to lift rated load N 140 220 320 340 360
Strands of load chain   1 1 1 2 3
Load chain diameter mm 6 8 10 10 10
Dimensions(mm) A   148 172 200 200 200
B   90 98 115 115 115
C   136 160 180 235 320
D   40 45 58 64 85
H   325 380 480 620 700
L   280 410 410 410 410
K   34 38 48 52 58
Net weight kg 7 11 21 31 46
Packing measurement cm 36x12.5x16 50x13.5x19 54x17x21.5 54x18x21.5 82x32x21.5
Extra weight per metre of extra lift kg 0.8 1.4 2.2 4.4 6.6
The Dawson lever hoist is a universal, manual hoist for lifting, tensioning and lashing in any direction. The ratchet lever hoist features compact design and robust, deep drawn, stamped steel construction. High quality materials ensure light weight without infringing reliability.

1.Low own weight, small mounting sizes and small lever force at full load.
2.Asbestos free brake, holding load at any desired height.
3.Top & bottom hooks are fitted with safety latches as standard.
4.The load chain can be pulled freely and easily through the hoist in both directions to attach the load or to tension the chain. For safety reason free chains can not be done when the hoist is under load.
5.Short hand lever with rubber grip.
6.Hand lever operates with little effort due to optimal gear ratio.
7.Drop forged steel suspension & load hooks are heat treated and fracture resistant. In case of dangerous overloading or abuse, the hook does not fracture but will slowly yield.
8.The hoist is fitted with high grade alloy load chain.
9.Grade 80 Zinc Plated FEC CHAIN from Japan & RUD CHAIN from Germany are available upon request.

10.Inspection of lever hoist & manuals


Application:

Lever hoist is a kind of portable and versatile hand-operated loading and pulling appliance, which is capable of being applied in electricity, mines, ship-buildings, construction sites, transports and telecommunication for installing equipment, lifting goods, pulling mechanical parts, bulk strapping and fastening, tightening fittings of wires, assembling and welding etc. It has exceptional advantages particularly for pulling in every limited narrow places in the upper air high above the ground and at any angles.


Welcome to buy the newest and competitive price DAWSON DS-HSH-A 623 Series Lever Block from our factory. We're one of the leading China manufacturers and suppliers, offering you the wholesale service and the OEM service at a discount. With CE certification, our products made in China in stock are high in quality and low in price. Please be free to get the free sample from us.
