DAWSON/OEM
13.5-250T
Availability: | |
---|---|
Quantity: | |
The turnbuckles from DAWSON can be used for tightening and lashing operations on land and at sea. Think of lashing shiploads or adjusting construction parts.Turnbuckles cannot be used for lifting purposes. You can choose between a bled or a jaw connection. The connections of the turnbuckles are geared to steel wire rope sockets and with the standard bow shackles and D-shackles. Safety factor of the turnbuckle is 5:1. For more information about this product, please contact us. We will be happy to inform you about the options.
Material: High tensile steel
Safety Factor: 5:1
Finish: Painted RAL 5015, RAL 1003 or RAL 3020
Temperature Range: -20℃ up to +200℃
Standard Certification:Certificate of Conformity
Item No. | SWL | L IN | L OUT | B2 (mm) | R2 (mm) | D2 (mm) | |
tons | kN | mm | Stud Eye | ||||
DS-HDT013.5EE | 13.5 | 133 | 840 | 1165 | 50 | 60 | 53 |
DS-HDT017EE | 17 | 167 | 920 | 1270 | 55 | 70 | 65 |
DS-HDT025EE | 25 | 245 | 975 | 1305 | 70 | 70 | 72 |
DS-HDT030EE | 30 | 294 | 1020 | 1390 | 70 | 75 | 74 |
DS-HDT035EE | 35 | 343 | 1100 | 1500 | 80 | 85 | 82 |
DS-HDT045EE | 45 | 442 | 1170 | 1650 | 90 | 95 | 93 |
DS-HDT055EE | 55 | 540 | 1270 | 1780 | 100 | 105 | 103 |
DS-HDT070EE | 70 | 687 | 1390 | 1940 | 100 | 115 | 111 |
DS-HDT085EE | 85 | 834 | 1515 | 2150 | 125 | 135 | 130 |
DS-HDT100EE | 100 | 981 | 1600 | 2330 | 125 | 145 | 143 |
DS-HDT120EE | 120 | 1177 | 1735 | 2330 | 140 | 170 | 155 |
DS-HDT160EE | 160 | 1570 | 1860 | 2460 | 160 | 190 | 181 |
DS-HDT200EE | 200 | 1962 | 2000 | 2620 | 170 | 200 | 193 |
DS-HDT250EE | 250 | 2453 | 2210 | 2880 | 190 | 260 | 253 |
Non-standard sizes or custom products available on request.
Proof Load Certificate on request.
Welcome to buy the newest and competitive price DAWSON HD Turnbuckle with Eye & Eye, Heavy Duty Rigging Screw EE Type for Tightening and Lashing from our factory. We're one of the leading China manufacturers and suppliers, offering you the wholesale service and the OEM service at a discount. With CE certification, our products made in China in stock are high in quality and low in price. Please be free to get the free sample from us.
For further information, please contact us. Email:info@dawson-group.com
SWL 13.5T HD Turnbuckles with Eye & Eye, SWL 17T HD Turnbuckles with Eye & Eye, SWL 25T HD Turnbuckles with Eye & Eye, SWL 30T HD Turnbuckles with Eye & Eye, SWL 35T HD Turnbuckles with Eye & Eye, SWL 45T HD Turnbuckles with Eye & Eye, SWL 55T HD Turnbuckles with Eye & Eye, SWL 70T HD Turnbuckles with Eye & Eye, SWL 85T HD Turnbuckles with Eye & Eye, SWL 100T HD Turnbuckles with Eye & Eye, SWL 120T HD Turnbuckles with Eye & Eye, SWL 160T HD Turnbuckles with Eye & Eye, SWL 200T HD Turnbuckles with Eye & Eye, SWL 250T HD Turnbuckles with Eye & Eye
SWL 13.5TON Heavy Duty Turnbuckles, SWL 17TON Heavy Duty Turnbuckles, SWL 25TON Heavy Duty Turnbuckles, SWL 30TON Heavy Duty Turnbuckles, SWL 35TON Heavy Duty Turnbuckles, SWL 45TON Heavy Duty Turnbuckles, SWL 55TON Heavy Duty Turnbuckles, SWL 70TON Heavy Duty Turnbuckles, SWL 85TON Heavy Duty Turnbuckles, SWL 100TON Heavy Duty Turnbuckles, SWL 120TON Heavy Duty Turnbuckles, SWL 160TON Heavy Duty Turnbuckles, SWL 200TON Heavy Duty Turnbuckles, SWL 250TON Heavy Duty Turnbuckles
SWL 13.5000KG HD Turnbuckles, SWL 17000KG HD Turnbuckles, SWL 25000KG HD Turnbuckles, SWL 30000KG HD Turnbuckles, SWL 35000KG HD Turnbuckles, SWL 45000KG HD Turnbuckles, SWL 55000KG HD Turnbuckles, SWL 70000KG HD Turnbuckles, SWL 85000KG HD Turnbuckles, SWL 100000KG HD Turnbuckles, SWL 120000KG HD Turnbuckles, SWL 160000KG HD Turnbuckles, SWL 200000KG HD Turnbuckles, SWL 250000KG HD Turnbuckles
Products Show:
Hot Tags: HD turnbuckle in stock, buy discount heavy duty turnbuckle, DAWSON BRAND high strength turnbuckle, turnbuckle for tightening and lashing China supplier, jaw & jaw turnbuckles China factory, UU type turnbuckle, bulk heavy duty type jaw and jaw turnbuckle, rigging screw, high tensile steel turnbuckle for lashing, heavy duty lashing turnbuckle, lashing turnbuckle
Other Related Products:
Package about Heavy Duty Turnbuckles:
DAWSON Testing Center:
