NOTE : G100 LIFTING CHAIN -- 3.2×9MM, 4×12MM, 5×15MM, 6.3×19MM, 7.1×21MM, 7.9×23MM, 8.7×23.8MM, 9×27MM, 9.6×28.6MM, 10×28MM, 11.2×34MM, 14×42MM IS ALSO AVAILABLE
| Code No. | DIA(mm) | Tolerance(mm) | Pitch | Width(mm) | Weight(kg/m) | WLL(T) | B.L(T) |
| mm | Tolerance | MIN. | MAX. |
| DS-C0013A | 4mm | ±0.16 | 12 | ±0.4 | 5.2 | 14.8 | 0.36 | 0.63 | 2.52 |
| DS-C0013B | 5mm | ±0.2 | 15 | ±0.5 | 6.5 | 18.5 | 0.56 | 1 | 4 |
| DS-C0013C | 6mm | ±0.24 | 18 | ±0.5 | 7.8 | 21.6 | 0.80 | 1.4 | 5.6 |
| DS-C0014 | 7mm | ±0.28 | 21 | ±0.6 | 9.5 | 25.2 | 1.1 | 1.9 | 7.6 |
| DS-C0015 | 8mm | ±0.32 | 24 | ±0.7 | 10.9 | 28.8 | 1.5 | 2.5 | 10 |
| DS-C0016 | 10mm | ±0.4 | 30 | ±0.9 | 13.5 | 36 | 2.3 | 4 | 16 |
| DS-C0018 | 13mm | ±0.52 | 39 | ±1.2 | 17.5 | 46.8 | 3.9 | 6.7 | 26.8 |
| DS-C0019 | 16mm | ±0.64 | 48 | ±1.4 | 21.5 | 57.6 | 5.8 | 10 | 40 |
| DS-C0020 | 18mm | ±0.9 | 54 | ±1.6 | 23.4 | 66.6 | 7.4 | 12.5 | 50 |
| DS-C0021 | 19mm | ±1 | 57 | ±1.7 | 25.6 | 68.4 | 8.1 | 14 | 56 |
| DS-C0022 | 20mm | ±1 | 60 | ±1.8 | 26 | 74 | 9 | 16 | 64 |
| DS-C0023A | 22mm | ±1.1 | 66 | ±2 | 29.5 | 79.2 | 11 | 19 | 76 |
| DS-C0023B | 23mm | ±1.2 | 69 | ±2.1 | 29.9 | 85.1 | 12 | 20 | 80 |
| DS-C0023C | 26mm | ±1.3 | 78 | ±2.3 | 33.8 | 96.2 | 15 | 26.5 | 106 |
| DS-C0023D | 32mm | ±1.6 | 96 | ±2.9 | 41.6 | 118 | 22.3 | 40.2 | 160.8 |
25% stronger than G80 chain
|
Product specifications:
3.2×9MM G100 Lifting Chain, 4×12MM G100 Lifting Chain, 5×15MM G100 Lifting Chain, 6×18MM G100 Lifting Chain, 6.3×19MM G100 Lifting Chain, 7×21MM G100 Lifting Chain, 7.1×21MM G100 Lifting Chain, 7.9×23MM G100 Lifting Chain, 8×24MM G100 Lifting Chain, 8.7×32.8MM G100 Lifting Chain, 9×27MM G100 Lifting Chain, 9.6×28.6MM G100 Lifting Chain, 10×28MM G100 Lifting Chain, 10×30MM G100 Lifting Chain, 11.2×34MM G100 Lifting Chain, 13×39MM G100 Lifting Chain, 14×42MM G100 Lifting Chain, 16×48MM G100 Lifting Chain, 18×54MM G100 Lifting Chain, 19×57MM G100 Lifting Chain, 20×60MM G100 Lifting Chain, 22×66MM G100 Lifting Chain, 23×69MM G100 Lifting Chain, 26×78MM G100 Lifting Chain, 32×96MM G100 Lifting Chain
3.2×9MM G100 Lifting Chain, 4×12MM Grade 100 Lifting Chain, 5×15MM Grade 100 Lifting Chain, 6×18MM Grade 100 Lifting Chain, 6.3×19MM Grade 100 Lifting Chain, 7×21MM Grade 100 Lifting Chain, 7.1×21MM Grade 100 Lifting Chain, 7.9×23MM Grade 100 Lifting Chain, 8×24MM Grade 100 Lifting Chain, 8.7×32.8MM Grade 100 Lifting Chain, 9×27MM Grade 100 Lifting Chain, 9.6×28.6MM Grade 100 Lifting Chain, 10×28MM Grade 100 Lifting Chain, 10×30MM Grade 100 Lifting Chain, 11.2×34MM Grade 100 Lifting Chain, 13×39MM Grade 100 Lifting Chain, 14×42MM Grade 100 Lifting Chain, 16×48MM Grade 100 Lifting Chain, 18×54MM Grade 100 Lifting Chain, 19×57MM Grade 100 Lifting Chain, 20×60MM Grade 100 Lifting Chain, 22×66MM Grade 100 Lifting Chain, 23×69MM Grade 100 Lifting Chain, 26×78MM Grade 100 Lifting Chain, 32×96MM Grade 100 Lifting Chain
Welcome to buy the newest and competitive price DAWSON 7.1mm G100 Round Lifting Chain, Grade 100 EN818-2 High Level Strength Alloy Hoist Lifting Chain 7.1x21mm from our factory. We're one of the leading China manufacturers and suppliers, offering you the wholesale service and the OEM service at a discount. With CE certification, our products made in China in stock are high in quality and low in price. Please be free to get the free sample from us.
For further information, please contact us. Email:info@dawson-group.com
Products Show:
Hot Tags: 7.1mm Lifting Chain,Lifting Chain China Supplier, Alloy Steel Lifting Chain Factory, Hot Sale Alloy Lifting Chains, Customized Alloy Steel Lifting Chains, Buy Discount G100 Alloy Lifting Chain, Low Price Alloy Lifting Chains, EN818-2 Alloy Lifting Chain Manufacturer, Grade 100 Alloy Chain, G100 Alloy Chain for Lifting Use, NACM Alloy Lifting Chain, G100 Alloy Chain for Lifting In Stock, Alloy Lifting Chain Free Sample
TUV CE Certificate about G100 EN818-2 Round Alloy Steel Link Chain for Chain Slings:
