DS-TPH Type Pipe Plate Clamp for Horizontal Lifting and Transporting

Working load limit(WLL):1.5-20T.
Use:
● For horizontal lifting and transporting of steel and concrete pipes.
● Compact shapes and relatively low own weight with a high lifting capacity.
● The surface is equipped with “special” plastic.
●The DS-TPH will be delivered per pair.
● Plastic cover is easy to change.
  • DAWSON/OEM

  • DS-TPH

  • 40 - 70mm

Availability:
Quantity:
DS-TPH Type Pipe Plate Clamp for Horizontal Lifting and Transporting

- Dawson Group Ltd. - China Manufacturer, Supplier, Factory

DS-TPH Pipe Plate Clamp - lifting clamps- Dawson Group Ltd. - China Manufacturer, Supplier
DS-TPH Pipe Plate Clamp - lifting clamps- Dawson Group Ltd. - China Factory, Manufacturer   DS-TPH Pipe Plate Clamp - lifting clamps- Dawson Group Ltd. - China Factory
DS-TPH Pipe Plate Clamp - lifting clamps - china manufacturer supplier - Dawson Group   Application of DS-TPH Type Pipe Plate Clamp 1.5-20T
DS-TPH Type Pipe Plate Clamp for Horizontal Lifting and Transporting - Dawson Group Ltd. - China Manufacturer, Supplier


Working load limit(WLL):1.5-20T.
Use:
● For horizontal lifting and transporting of steel and concrete pipes.
● Compact shapes and relatively low own weight with a high lifting capacity.
● The surface is equipped with “special” plastic.
●The DS-TPH will be delivered per pair.
● Plastic cover is easy to change.


Part No. Model WLL(tonnes) per pair Jaw Opening(mm) Dimensions(mm) Weight(kg)
A B C D E T
DS-0159 DS-TPH1.5 1.5 40 122 30 195 70 39 25 2.2
DS-0160 DS-TPH3 3.0 40 122 30 195 70 39 25 2.6
DS-0161 DS-TPH4 4.0 50 122 30 215 70 39 28 2.9
DS-0162 DS-TPH6 6.0 50 122 30 215 70 39 28 3.5
DS-0163 DS-TPH8 8.0 70 126 30 240 70 39 28 3.8
DS-0164 DS-TPH12 12.0 70 160 30 260 90 45 36 6.7
DS-0165 DS-TPH16 16.0 70 168 30 272 90 50 37 9.4
DS-0166 DS-TPH18 18.0 70 183 30 292 90 50 37 13
DS-0166A DS-TPH20 20.0 70 220 30 333 90 50 45 19.3


Welcome to buy the newest and cheap DAWSON DS-TPH type pipe plate clamp for horizontal lifting and transporting from our factory. We're one of the leading China manufacturers and suppliers, offering you the wholesale service and the OEM service at a discount. With CE certification, our products made in China in stock are high in quality and low in price. Please be free to get the free sample from us.

 DS-TPH Type Pipe Plate Clamp for Horizontal Lifting and Transporting - Dawson Group Ltd. - China Manufacturer, Supplier

Products Show :

DS-TPH Type Pipe Plate Clamp for Horizontal Lifting and Transporting - Dawson Group Ltd. - China Manufacturer, Factory, Supplier
Pipe Plate Clamp for Horizontal Lifting and Transporting - Dawson Group Ltd. - China Manufacturer, Factory, Supplier
Pipe Plate Clamp for Horizontal Lifting and Transporting - Dawson Group Ltd. - China Manufacturer, Supplier, Factory
DS-TPH Type Pipe Plate Clamp for Horizontal Lifting and Transporting - Dawson Group Ltd. - China Supplier, Factory, Manufacturer
DS-TPH Type 4T Pipe Plate Clamp for Horizontal Lifting and Transporting - Dawson Group Ltd. - China Manufacturer, Supplier, Factory
DS-TPH Type Pipe Plate Clamp for Horizontal Lifting and Transporting - Dawson Group Ltd. - China Manufacturer, Supplier
DS-TPH Type Pipe 6T Plate Clamp for Horizontal Lifting and Transporting - Dawson Group Ltd. - China Manufacturer, Supplier, Factory
DS-TPH Type Pipe Plate Clamp for Horizontal Lifting and Transporting - Dawson Group Ltd. - China Manufacturer, Supplier, Factory

DS-TPH Type Pipe Plate Clamp for Horizontal Lifting and Transporting - Dawson Group Ltd. - China Manufacturer, Supplier, Factory
DS-TPH Type Pipe Plate Clamp for Horizontal Lifting and Transporting - Dawson Group Ltd. - China Supplier, Factory, Manufacturer
DS-TPH Type Pipe Plate Clamp for Horizontal Lifting and Transporting - Dawson Group Ltd. - China Factory, Manufacturer, Supplier

DS-TPH Type Pipe Plate Clamp for Horizontal Lifting and Transporting - Dawson Group Ltd. - China Manufacturer, Supplier, Factory

DS-TPH Pipe Plate Clamp - China manufacturer supplier

Hot Tags: Pipe Clamp, Pipe Plate ClampSteel Pipe ClampConcrete Pipe ClampPipe Clamp for LiftingChina Steel Pipe Lifting Clamp SupplierWholesale Concrete Pipe ClampHot Sale Concrete Pipe Plate ClampPipe Lifting Clamp FactoryHorizontal Lifting Clamp ManufacturerPipe Plate Clamp FactoryChina Exporter Clamp for Concrete PipesCheap Price Concrete Clamp for LiftingLow Price Concrete Pipe ClampDawson Brands Concrete Lifting Clamp, Concrete Pipe Plate Clamp In StockLifting Clamp for Concrete Pipes Free SamplePipe Lifting Clamp OEMBuy Discount Concrete Pipe Lifting ClampCustomized Steel Pipe Lifter Clamp


Other Related Products:

DS-CDD Type Vertical Plate Clamp with Safety Lock - Dawson Group Ltd. - China Manufacturer, Supplier, Factory
DS-L Type Horizontal Plate Clamp - Dawson Group Ltd. - China Manufacturer, Supplier, Factory
DS-PDB Type Industry Standard Horizontal Plate Clamp for Lifting and Transport - Dawson Group Ltd. - China Manufacturer, Supplier, Factory
DAWSON Plate Clamp for Lifting - Dawson Group Ltd. - China Manufacturer, Supplier
DAWSON Plate Clamp for Lifting and Transport - Dawson Group Ltd. - China Manufacturer, Supplier
DAWSON Plate Clamp for Lifting - Dawson Group Ltd. - China Factory, Manufacturer, Supplier

Lifting Clamps, Vertical Plate Clamp - Dawson Group Ltd. - China Manufacturer, Supplier, Factory

other related products
DS-CD Type Universal Plate Clamp for Lifting and Transporting Steel Plates - Dawson Group Ltd. - China Manufacturer, Supplier, Factory
DS-YG Type Round Stock Grabs Lifting Clamp for Horizontal Transport - Dawson Group Ltd. - China Manufacturer, Factory, Supplier
DS-PDK Type Adjustable Horizontal Multi Plate Clamp - Dawson Group Ltd. - China Manufacturer, Supplier, Factory
DS-PDL Type Horizontal Plate Clamp - Dawson Group Ltd. - China Manufacturer, Supplier, Factory
DS-NHK Non-marking Horizontal Lifting Clamp Plate Clamps - Dawson Group Ltd. - China Manufacturer, Factory, Supplier


Application of Pipe Plate Lifting Clamps:

Application of Pipe Plate Clamp for Horizontal Lifting and Transporting - Dawson Group Ltd.- China Supplier

Application of Lifting Clamps - Dawson Group Ltd. - China Manufacturer, Supplier, Factory

Application for DAWSON Horizontal Plate Clamp - Dawson Group Ltd. - China Supplier, Factory
Application for DAWSON Horizontal Plate Clamp - Dawson Group Ltd. - China Manufacturer, Supplier
Application for DAWSON Horizontal Plate Clamp - Dawson Group Ltd. - China Manufacturer, Factory
Application for DAWSON Horizontal Plate Clamp - Dawson Group Ltd. - China Manufacturer, Supplier, Factory


Safety lifting
● The lifting clamps are suitable for lifting and transporting of steel plates with a maximum hardness of 37  HrC (345HB,1166 N/mm⊃2;).
● The lifting clamps are suitable for usage in normal atmospheric conditions, between -40℃ and +100℃
● Never overload a clamp and prevent the jerking of loads.
● When loading always use the whole jaw depth.
● Never lift more than one plate at the same time.
● Always keep your distance during lifting and descending of a load.
● Prevent situations that anybody is under the load.

● Any welding to the clamp is forbidden, this can influence the hardness and toughness of the clamp.


Application of Safety Lifting
