800LBS 1200LBS 1600LBS 1800LBS 2600LBS SS304 Small Stainless Steel Reversible Hand Winches with Brake for Pulling

Characteristics

-Positive action brake can hold the load in any position.

-Compact, light weight and rugged construction.

-The brake is sealed in strong steel cover to protect from dust and rain.

-Stainless steel material(optional) for resistance to rust and corrosion.

-Only for pulling.

This product is suitable for occasions with high cleanliness requirements, such as pharmaceutical processing, food processing, sewage treatment, marine engineering and other industries.

All parts of the DS-JC hand winch except the shaft sleeve, friction plate, handle sleeve, etc. are made of 304 stainless steel material, and the appearance is exquisite.

The key pinion parts are treated at low temperature, and the copper-based shaft sleeve is strong and wear-resistant, and the whole machine has a good anti-rust and corrosion-resistant effect.

Model		DS-JC-800	DS-JC-1200	DS-JC-1600	DS-JC-1800	DS-JC-2600
Capacity(LBS)		800	1200	1600	1800	2600
Test Load(KN)		3.56	5.35	7.12	8	11.5
Speed Ratio		2.8:1	4.2:1	5:1	5:1	10:1
Wire Rope(φmm x Lm)		4mmx15m	4mmx25m	5mmx20m	5mmx25m	6mmx25m
Dimension(mm)	A	122	156	173	203	216
	B	117	184	209	256	293
	C	88	88	99	107	127
	D	170	204	204	319	319
	E	27	27	27	27	27
	F	277	280	287	283	305
	G	50	51	60	60	63
	H	109	109	109	109	109
Net weight(kg)		2.6	3.6	4.3	7.8	10.3

Note: The rated load capacity refers to the maximum load capacity when the first layer of wire rope is wound, and the corresponding proportion decreases with the increase of the number of layers of the wire rope.

Under load, keep more than three turns of rope in the drum.

Certificate:

Products Detail Show:
